8d报告真实案例（8D报告应用案例分享）

8D报告是常用的问题分析，也是异常回复的格式。按照8D报告的思路，我们可以一步步地去分析解决完善所面临的问题。

中文版8D报告格式已经很常见了，一搜一大把。今天我们所要给大家展示的是英文版的8D报告，包括每一步的名称，以及一个案例，供大家参考。

8D, it definitely means there are 8 disciplines to solve a issue, shown it as below.

建立团队 D1 build team

(It should include all the function teams)

问题描述 D2 issue description

Downstream customer feedback there are 8% fiber between glass and Frame gap.

(5W2H is always used in this discipline)

临时围堵对策 D3 containment action

Quarantine all our company inventory and customer's, arrange manpower to remove the fiber.

原因分析及效果验证 D4 analysis and identify the root cause

1,Incoming Frame have fiber, it would be assemblied in the gap between Frame and glass.

2,floating fiber of glass and Frame surface is assemblied in the gap.

(fishbone, 5W2H, brainstorm, scatter plot, pareto chart are always used)

长期改善对策 D5 corrective action

There are 2 actions.

1, incoming Frame 100% inspect fiber before shipping to assembly station

2, add ion Fan to blow away floating fiber on glass and Frame surface, add dust sticky tape to adheive the floating fiber.

最终效果效果验证 D6 effect verification

Arrange ops 100% inspect fiber before shipping out.

预防及标准化 D7 standardize

Add fiber inspection into IS list, and QC sampling check.

团队总结 D8 team summary
